U - Type 3 Axles Side Tipper Semitrailer -- The self unloading semi-trailer is suitable for the transportation
of bulk goods such as coal, ore, construction materials, etc. Dump
semi-trailer can be divided into two categories according to their
uses: one is heavy-duty and super heavy-duty dump trucks for
off-road transportation, mainly responsible for large-scale mining,
engineering and other transportation tasks, usually used together
with excavators. The other type of light and medium-sized ordinary
dump truck for highway transportation mainly undertakes the
transportation of sand, soil, coal and other loose goods, which is
usually used together with loaders.
U - Type 3 Axles Side Tipper Semitrailer Export To Kenya, Tanzania,
Zambia, Ghana ,etc
| Main Dimensions |
| Dimension | 9200*2400*3200mm ( outside) 9000*2200*1500mm (work space ) |
| Tare weight | About 10000KGS |
| Total Volume(m3) | 30 m³ or less than 50tons |
| Side wall thickness(mm) | 2.3mm Q235 steel (three or five door opening door ) |
| Bottom plate thickness(mm) | 3mm diamond plate /Q235 steel |
| Lifting system | Full set of Hydraulic Lifting system (Four diameter125 lifting
cylinder, and one diameter140 lifting cylinder.) |
| Chassis |
| Main Beams | Height:500mm, upper plate is 16mm,middle is 8mm(double+three
plate),down plate is 18mm,material is Q345B steel |
| Axle | 3 axles, FUWA/HUAJING brand 13tons or 16tons per axles |
| Landing Gear | JOST (D200T)or CHINA BRAND 28T |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension/ America type / |
| Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer |
| Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; one piece of 45L air
tanks. |
| Rim | 9.00-22.5/8.00-20/8.5-20 China Brand |
| Tire | /12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional |
| ABS | Optional |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of
anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box |
| Shipping Terms | By Bulk Cargo or roro, the trailer size can be design according to
your special requirement , the tractor truck can be choose 6*4
model . |
Advantages of U - Type 3 Axles Side Tipper Semitrailer
1. The self unloading semi-trailer is suitable for the
transportation of bulk goods such as coal, ore, construction
materials, etc. Dump semi-trailer can be divided into two
categories according to their uses: one is heavy-duty and super
heavy-duty dump trucks for off-road transportation, mainly
responsible for large-scale mining, engineering and other
transportation tasks, usually used together with excavators. The
other type of light and medium-sized ordinary dump truck for
highway transportation mainly undertakes the transportation of
sand, soil, coal and other loose goods, which is usually used
together with loaders.
2. The carriage is rollover, which can effectively improve the
transportation efficiency of bulk goods transported by the loader.
3. The frame and the longitudinal beam of the carriage are welded
with high-quality manganese plate, and there are dustpan and
rectangular box. It has high strength, strong lifting force, good
rigidity and toughness, strong bearing capacity and no permanent
deformation.
Qingdao Genron International Trade Co., Ltd Main Business is
Exporting all kinds of trailers, trailer parts and Man-hand Welding
Machinery, Automatic Welding machinery, Trailer Production Line
Etc. We have our own factory which produce trailers for more than
15 years, Our CEO Mrs. Zhao have 11 years export Construction and
trailer trucks experiences; She have visited more than 22 countries
for checking trailer truck markets. We can supply the right product
in shortest ways and cheapest value.
The strong advantage of Genron company with other trading company
is we have our own professional technical design team.If you
uncertain your products or your own design,we can go to visit you
,help you checking and analysis your market and gave you special
and right design according to your country situation. As our more
than 11 years overseas visited record and exporting business
experience focus on the trailer and truck filed ,we can gave you
the right product in very short way.
Why do you choose Genron?
11 years overseas experience :
As our more than 11 years overseas produce and exporting business
experience focus on the trailer and truck filed ,We used nine years
visited
On Ghana, Burkina faso, Cameroon, Nigeria, Mozambique, Zambia
,Tanzania ,Kenya, Malaysia ,Indonesia ,Philippine, Vietnam ,LAOS ,
Mayanmar, Algeria, Dubai.
Mirror Trading :
we will gave you the best price and quality product. Because we
hope our cooperation like mirror ,Customer as mirror ,one side is
factory ,inside is Genron,
We Minimize all loses that may arise from the producers .We respond
to the demands and requirements of the companies , we work with in
the most effective way and as soon as possible.
Professional Technical Team:
The strong advantage of Genron compare with other trading company
and company is we have our own professional design team: One
engineer Mr.Fanming Bu (working for CIMC company five years, design
trailer and production line six years),Five technical person:
Mr.Wenming Zhao(design tanker trailer for 11 years),Mr. Xianzhen
Zhao(design welding machinery four years), Mr.Haifeng Liu(design
trailer axles four years). Mr.Zuoliang Yang( design tipper trailer
six years).Mr.Jihe Cao(Design tanker trailer five years).
